MaxiTPMS TS401

Autel MaxiTPMS TS401 is Autel new generation TPMS diagnose and service tool, it's unparalleled sensor coverage and easy to use feature make it become most customer's beloved TPMS tool.


Autel MaxiTPMS TS401 provides you easy and quick access to the faulty TPMS sensor to help you increase customer satisfaction and boost your bottom line.

Autel MaxiTPMS TS401 Feature:
1. Unparalleled sensor coverage – activates ALL magnetic, frequency and tire deflation triggered sensors on all vehicles sold worldwide

2. Reads data including sensor ID, tire pressure, temperature, battery condition, OE part number, relearn information

3. Receives both 315MHz and 433MHz signals

4. Provides visual and audible responses to confirm sensors are working properly

5. Checks Remote Keyless Entry (Key FOB) for transmissions

6. Accurate diagnosing result – a tool users can trust

7. Graphs vehicle with 4 or 5 wheels to simplify the diagnostic process

8. Pre-selection process offers faster activation and diagnostics

9. Incredibly easy to use with intuitive navigation and step-by-step on-screen instructions

10. Built-in rechargeable Li-polymer battery

11. One year free online software updates

12. Proper LF signal to prevent being fooled by other RF signals

13. Multilingual support

14. Saves up to 10 TPMS records for future data review

15. Automatic power-off to preserve battery life

16. Modular design allows for future capability expansions

17. Ergonomic design features strong housing and protective rubber boot

DisplayBacklit, 128 x 64 pixel display with contrast adjustment
Power3.7 V Li-polymer battery; 1820 mAh
Operating Temperature0 to 50°C (32 to 122°F)
Storage Temperature-20 to 70°C (-4 to 158°F)
Dimensions (W x H x D)195.5 mm (7.7") x 104 mm (4.09") x 37.5 mm (1.48")
Weight0.37 kg (0.82 lb.)
Warranty1 year
Software UpdateFree

ComparisonTS608MS906 TSTS601TS508TS501TS408TS401TPMS PAD
TPMS function
Quick Mode & Advance Mode
Activate TPMS sensors
Read sensor data
TPMS diagnose, one step for complete TPMS health check
Read/clear TPMS DTCs; on-screen DTC description
Scan TPMS sensor ID and copy ID into MX-Sensor
Manual input OE ID into MX-sensor
Program MX-Sensor by auto creating sensor ID
Read Sensor ID by OBD and copy ID into MX-Sensor
Relearn by OBD function
Relearn procedure guide on the tool
Check Key FOB
Read TPMS live data
Tire Type/Pressure selection
Other TPMS special functions
TPMS Toolkit (other function)
Diagnostic function
Basic OBDII code reader
Read/clear codes for all electronic systems
Support all 10 test modes of the latest J1979 OBDII test specs
Enhanced OBDII Mode 6
Display live data in text, graph & analog for easy data review
Relearn parking brake pad after replacement;
Reset Steering Angle Sensor (SAS);
Reset service mileage and service intervals;
Forced regeneration and adjusting injectors;
Support battery registration and reset
Support IMMO functions
Complete diagnostic function
Tool features
Built-in rechargeable li-ion battery
Strong housing with protective rubber boot
Print TPMS sensor data via PC
Internet updatableWIFIWIFISD cardUSBSD cardUSBUSBUSB
Multilingual support
Historical test records
Software Update1 year free1 year freefreefreefreefreefreefree
Limited one year warranty

1pc x TPMS TS401 main unit
1pc x USB Cable
1pc x Charger
1pc x Magnet
1pc x User's manual
1pc x CD
1pc x Carrying case
